Modular Abattoirs
By Kometos
Kometos Slaughterhouses for Sheep and Reindeer
Kometos Finmodules slaughterhouses for sheep and reindeer are modular facilities designed for efficient, hygienic slaughtering in demanding conditions, including Arctic environments. The Tundratek range can be configured from compact four-module plants to larger seventeen-module slaughterhouse and production facilities.
Overview
- ApplicationsSheep, reindeer, deer and goat slaughterhouses
- Capacity range50–400 reindeer or sheep / 8 h depending on model
- Module range4, 5, 7, 8 and 17 module configurations
- Approx. size168–714 m²
- DeliveryCustom modular slaughterhouse and production plant
Finmodules Tundratek 4-module slaughterhouse (T-500.4)
- Product number1001055004
- Capacity50–80 reindeer or sheep / 8 h
- Carcass weight35 kg
- Cooling capacity80 reindeer or sheep / day
- Electricity400 V, 50 Hz, 160 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules4 pcs
- Approx. size168 m²
- UnitsSlaughtering; staff room; cooling of carcasses; cutting/packing; freezing tunnel; technical premise
Finmodules Tundratek 5-module slaughterhouse (T-501.5)
- Product number1001055015
- Capacity100 reindeer or sheep / 8 h
- Carcass weight35 kg
- Cooling capacity100 reindeer or sheep / day
- Electricity400 V, 50 Hz, 160 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules5 pcs
- Approx. size210 m²
- UnitsStunning; slaughtering; carcass cooling; by-product/technical; social premises
Finmodules Tundratek 7-module slaughterhouse (T-501.7)
- Product number1001055017
- Capacity160 reindeer or sheep / 8 h
- Carcass weight35 kg
- Freezing capacity5,000 kg reindeer or sheep / day
- Electricity400 V, 50 Hz, 350 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules7 pcs
- Approx. size250 m²
Finmodules Tundratek 8-module slaughterhouse (T-502.8)
- Product number1001055028
- Capacity200 reindeer or sheep / 8 h
- Carcass weight35 kg
- Freezing capacity6,000 kg reindeer or sheep / day
- Electricity400 V, 50 Hz, 350 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules8 pcs
- Approx. size324 m²
Finmodules Tundratek 17-module slaughterhouse (T-504.17)
- Product number10010550417
- Capacity400 reindeer or sheep / 8 h
- Carcass weight35 kg
- Cooling capacity400 reindeer or sheep / day
- Electricity400 V, 50 Hz, 800 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 160 mm
- Modules17 pcs
- Approx. size714 m²
Why choose this Kometos solution?
- Ready-to-use slaughterhouseBuilt and tested before delivery, with training available for operating and maintenance staff.
- Arctic capabilityMaterials and insulation are selected for large temperature variations and demanding locations.
- Complete meat productionCan include slaughtering, processing, cooling, freezing, curing and by-product areas.
Source product family: Kometos Finmodules. For pricing, layout planning and specification checks, contact Global Food Technology.
