Modular Abattoirs
By Kometos
Kometos Slaughterhouses for Cattle
Kometos Finmodules cattle slaughterhouses provide flexible modular facilities with high hygiene, efficient workflow and strong expandability. Solutions range from three-module cattle slaughterhouses to larger cattle or sheep plants, with the modules supplied ready for connection to utilities and designed for fast installation.
Overview
- ApplicationsCattle slaughterhouses, and combined cattle or sheep facilities
- Capacity rangeApprox. 10–20 cattle / day depending on model
- Module range3, 4, 5, 9 and 13 module configurations
- Approx. size126–506 m²
- DeliveryTurnkey modular plant with training and commissioning support
Finmodules 3 module plant for cattle (SINA-N5.3)
- Product number1001020503
- Capacity16–20 cattle / day (8 h)
- Live weight700 kg
- CoolingAs ¼ carcasses
- Electricity400 V, 50 Hz, 125 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules3 pcs
- Approx. size126 m²
- UnitsSlaughtering premises; cooling of carcasses; technical room; staff room; optional waste material premises
Finmodules 4 module plant for cattle (SINA-N5.4)
- Product number1001020504
- Capacity16–20 cattle / day (8 h)
- Live weight700 kg
- CoolingAs ¼ carcasses
- Electricity400 V, 50 Hz, 125 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules4 pcs
- Approx. size168 m²
- UnitsSlaughtering; carcass cooling; technical room; staff room; by-products; cutting; packing; warehouse
Finmodules 5 module plant for cattle (SINA-N5.5)
- Product number1001020505
- Capacity18–20 cattle / day (8 h)
- Live weight700 kg
- CoolingAs ¼ carcasses
- Electricity400 V, 50 Hz, 400 A
- Water50–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules5 pcs
- Approx. size210 m²
- UnitsSlaughtering; carcass cooling; technical room; staff room; by-products; cutting; packing; warehouse
Finmodules 7 module plant for cattle or sheep (SINA-NL7/1.9)
- Product number1001020709
- Cattle capacity10–15 cattle / day (8 h), live weight 700 kg
- Sheep capacity40–50 sheep / day (8 h), carcass weight 25 kg
- CoolingCattle as ½ carcasses; sheep as whole carcasses
- Electricity400 V, 50 Hz, 400 A
- Water70–100 l/min, 4 bar, 2”
- Waste waterø 160 mm
- Modules9 pcs
- Approx. size480 m²
Finmodules 13 module plant for cattle or sheep (SINA-NL20/5.14)
- Product number1001022014
- Cattle capacity16–20 cattle / day (8 h), live weight 700 kg
- Sheep capacity150–170 sheep / day (8 h), carcass weight 35 kg
- CoolingCattle as ½ carcasses; sheep as whole carcasses
- Electricity400 V, 50 Hz, 480 A
- Water70–100 l/min, 4 bar, 2”
- Waste waterø 110 mm
- Modules13 pcs
- Approx. size506 m²
Why choose this Kometos solution?
- Fast turnkey deliveryKometos builds, equips and tests the modules before delivery.
- Energy-saving designMechanical ventilation and heat recovery can reduce energy demand.
- Complete production setupThe slaughterhouse can be integrated with cutting, packing, cooling and by-product facilities.
Source product family: Kometos Finmodules. For pricing, layout planning and specification checks, contact Global Food Technology.
